Feature | 17000 |
Cooling | |
Capacity | W 17000 |
Input | W 5090 |
EER | W/W 3.34 |
Heating | |
Capacity | W 20000 |
Input | W 5450 |
COP | W/W 3.67 |
Indoor air flow rated (Hi/Med/Lo) | m³/h 2000 |
Indoor noise level (Hi) | dB (A) 49 |
Indoor Unit | |
Dimension (W × H × D) | mm 840×298×840 |
Packing (W × H × D) | mm 996×420×956 |
Net/Gross weight | kg 30/39 |
Compressor | |
Model | LNB42FSAMC |
Type | ROTARY |
Brand | MITSUBISHI |
Outdoor noise level (sound pressure) | dB (A) 60 |
Outdoor Unit | |
Dimension (W × D × H) | mm 950×1386×340 |
Packing (W × D × H) | mm 1110×1527×460 |
Net/Gross weight | kg 108/112 |
Refrigerant type/Quantity/Type | R410A |
Charged volume | kg 3.50 |
Refrigerant piping – Liquid side/Gas side | mm 9.52/19.05 |
Max. pipe length | m 50 |
Max. difference in level | m 30 |
Ambient temperature – Cooling | °C 15-43 |
Ambient temperature – Heating | °C -10-24 |
Qty per 20’/40’/40’HQ | 24/47/47 |
Power Supply | V/Ph/Hz 220-240/1/50 |
